Product description
Eppendorf Xplorer
®
/Eppendorf Xplorer
®
plus
English (EN)
19
3.6.2 Status bar
The selected operating mode is displayed here during operation. In edit mode, the name
of the parameter to be edited is displayed.
3.6.3 Main field
All parameters of the operating mode are displayed simultaneously during dispensing. A
black arrow indicates the direction of the next piston movement.
In edit mode, the parameter to be edited is marked in red.
Some of the dispensing parameters in the main field include:
• Dispensing volume
• Speed: 8 speeds for aspiration and dispensing.
• Counter Number of conducted dispensing steps. Optional setting in the Pip mode.
3.6.4 Footer
Assignment of the softkeys with variable functions.
Some of the softkeys in the footer are:
• Edit: Open the edit mode.
• Next: Select next parameter.
• End: Exit the edit or help mode.
• Help: Show help.
• History: Display the last dispensing settings of the accessed mode .
The right softkey can be assigned to Help or History. The assignment of the
softkey can be defined in the options (Opt). The softkey is assigned to Help when
delivered.
If the right Help softkey is activated, the softkey can be used to display
information on the selected operating mode.
If the History softkey is activated, it can be used to call the most recently
executed dispensing operations.
