Epson C8-B - Page 101

C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-59 Rev.1
Install the Arm1 center cover.
Install the Arm1 side cover.
After assembly, perform calibration of Joint #2.
3.2 Calibration
5
6
7
3
2
1
5
6
6
Installing the Motor Unit
