C8-B/C12-B Service Manual Maintenance Information Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 1-14 Rev.1
Inject grease from the grease nipple using a grease gun.
SK-1A: 11 g
Remove the grease nipple from the Joint #1 grease inlet.
Attach the grease plug to the Joint #1 grease inlet.
POINT
If the grease plug is damaged or deteriorated, replace it with a new one.
Install the Arm #1 side cover.
4
Grease Gun
5
6
7
