C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-193 Rev.1
Install the Arm4 side cover (both sides).
After assembly, perform calibration of Joint #5.
3.2 Calibration
6
7
Installing the Motor Unit
5
3
1
4
6
6
