C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-221 Rev.1
Install the Air Tube.
Install the Arm4 side cover (both sides).
After assembly, perform calibration of Joint #6.
3.2 Calibration
4
Air Tube
5
6
3
2
1
5
Installing the Motor Unit
5
4
3
