C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-229 Rev.1
6. Disconnect the brake power supply connector (CN411).
POINT
Pull the cables with CN410-1 and CN411-2 through the hole as shown in the figure.
CN411-2
CN410-1
CN411
Removing the Cable Unit
