C8-B/C12-B Service Manual Maintenance Information Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 1-23 Rev.1
Attach the grease nipple to the Joint #5 grease inlet.
CAUTION
The grease plug attaching hole located near the label with “5” printed is the Joint #5
grease inlet.
Be careful not to confuse it with the Joint #6 grease inlet.
Inject grease from the grease nipple using a grease gun.
SK-1A: 1 g
CAUTION
Be careful not to mix with the grease used in the Joint #6 (SK-2).
Remove the grease nipple from the Joint #5 grease inlet.
2
3
Grease Gun
4
