C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-314 Rev.1
Protection Model
A. Removal
Remove the base cover.
POINT
When removing the base cover, also remove the base bottom gasket.
1
S01: 8-M4x10
A
Base cover
1
