C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-360 Rev.1
Remove the Connector Plate.
3
S01: 11-M4x10
A
Connector Plate
3
2
1
Removal
