C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-367 Rev.1
Remove the connector sub plate.
CAUTION
Cables are connected internally, so do not pull with force when removing.
3
S01: 4-M4x10
with seal washer
A
Connector sub plate
3
Standard Model/Cleanroom Model
