Removing the Motor Unit
Turn ON the controller.
Release the J2 brake, and manually push and move Arm2 until it comes in contact with
the mechanical stopper, and push it against Arm1.
CAUTION
Arm2 falls by its weight when the J2 Motor unit is removed. Release the brake and tilt
Arm2 in advance.
Turn OFF the Controller.
Remove the J2 Timing Belt.
1
2
3
4
2
4
6
5
