SC-F2000 Revision C
ADJUSTMENT ADJUSTMENTS (Sequence) 218
Confidential
[Blue]: Button or menu name on the program screen / [Black]: Button or menu name on the operation panel of the printer
4.4 ADJUSTMENTS (Sequence)
This mode displays the required adjustments per replaced part and executes the
adjustments in order.
PROCEDURE
1. Click [ADJUSTMENTS (Sequence)] from the main menu.
2. Select the name of the part to be replaced.
3. Select the adjustment item that you want to execute.
4. Follow the instructions on the screen to execute the adjustment.
5. Click to return to the main menu.
Figure 4-11. ADJUSTMENTS (Sequence)
The text of the executed adjustment is colored to be distinguished.
Check marks go back to the previous state once the main menu is
displayed.
To Next Page
