Epson SC-F2000 User Manual

SC-F2000 Revision C
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 72
Confidential
3.4.3 Housing
3.4.3.1 PRINTER COVER
1. Open the PRINTER COVER vertically.
2. Remove the four screws, and remove the PRINTER COVER in the direction of the
arrow.
A) Silver M4x8 Cup P-tite screw: 4 pcs
Figure 3-15. Removing the PRINTER COVER
A D J U S T M E N T
R E Q U I R E D
When replacing/removing this part, refer to “4.1.2 Adjustment
Items and the Order by Repaired Part” (p194) and make sure to
perform the specified operations including required adjustment.
A
A
A
A
PRINTER COVER
