Epson SC-F2000 User Manual

SC-F2000 Revision C
ADJUSTMENT Electrical Component Adjustments 278
Confidential
[Blue]: Button or menu name on the program screen / [Black]: Button or menu name on the operation panel of the printer
4.14.6 USB Port and Network Communication Check
EXECUTION MODE
Normal Mode
PROCEDURE TO CHECK THE USB CONNECTION STATUS
1. Turn the printer ON.
2. Start the Service Program and select [USB port and Network Communication
Check].
3. Click [USB].
When the communication is available, the LCD flashes several times.
PROCEDURE TO CHECK THE NETWORK CONNECTION STATUS
1. Turn the printer ON.
2. Start the Service Program and select [USB port and Network Communication
Check].
3. Enter the IP address of the printer, and click [NETWORK].
When the network communication is available, the LCD flashes several times.
Figure 4-92. [USB port and Network Communication Check] Screen
