SC-F2000 Revision C
ADJUSTMENT References 222
Confidential
[Blue]: Button or menu name on the program screen / [Black]: Button or menu name on the operation panel of the printer
4.8 References
This function allows you to view the following information (PDF files).
Control panel menus in the Normal Mode
Control panel menus in the Serviceman Mode
Wiring diagrams
PROCEDURE
1. Click [References] from the main menu.
2. Select [Panel Menu Map] or [Wiring Diagrams] and click [Open].
Figure 4-15. References
