APPENDIX Part names used in this manual 310
Confidential
6.4 Part names used in this manual
To make it easier to locate the target part from its part name, this manual uses the part
names different from the ASP part names. The table below shows the conversion of the
part names used in this manual and the corresponding ASP part names.
Table 6-1. Conversion Table
Part name used in this manual ASP part name
Ref.
(Ch3
sec.No.)
Housing
PRINTER COVER COVER,PRINTER 3.4.3.1
LEFT HOUSING PLATE
DECORATION
PLATE,HOUSING
3.4.3.2
RIGHT HOUSING PLATE
DECORATION
PLATE,HOUSING
3.4.3.3
PANEL ASSY PANEL ASSY.,A ESL,ASP 3.4.3.4
FILTER Filter 3.4.3.5
REAR COVER SUB ASSY N/A 3.4.3.6
REAR COVER N/A 3.4.3.7
FRONT SUB COVER COVER,FRONT 3.4.3.8
LEFT FRONT COVER N/A 3.4.3.9
RIGHT FRONT COVER N/A 3.4.3.9
LEFT IC COVER COVER,IC,LEFT,ASSY,ASP 3.4.3.10
RIGHT IC COVER COVER,IC,RIGHT,ASSY,ASP 3.4.3.11
LEFT IH COVER HOLDER,IC,LEFT 3.4.3.12
RIGHT IH COVER HOLDER,IC,RIGHT 3.4.3.13
LEFT COVER ASSY HOUSING,LEFT,ASSY,ASP 3.4.3.14
RIGHT HOUSING CAP CAP,HOUSING 3.4.3.15
RIGHT COVER ASSY HOUSING,RIGHT,ASSY,ASP 3.4.3.15
LEFT IC COVER SENSOR LEAF SENSOR 3.4.3.16
RIGHT IC COVER SENSOR LEAF SENSOR 3.4.3.17
PRINTER COVER OPEN
SENSOR
LEAF SENSOR 3.4.3.18
REAR FILTER ASSY FILTER,REAR,ASSY.,ASP 3.4.3.19
Electric Circuit
Components
MAIN BOARD BOARD ASSY.,MAIN 3.4.4.1
MAIN-B BOARD BOARD ASSY.,MAIN 3.4.4.2
SUB-B BOARD BOARD ASSY.,SUB 3.4.4.3
POWER SUPPLY BOARD
BOARD ASSY.,POWER
SUPPLY
3.4.4.4
CR SUB BOARD BOARD ASSY.,SUB 3.4.4.5
Carriage Mechanism/
Ink System
Mechanism
CR COVER - 3.4.5.1
DAMPER KIT DUCT,CR,ASSY,ASP 3.4.5.2
PRINT HEAD PRINT HEAD,ID7560-7 3.4.5.3
INK MIST COVER ASSY PAD AND SHEET KIT ASP. 3.4.5.4
CR SCALE SCALE,CR 3.4.5.5
CR MOTOR ASSY MOTOR ASSY.,CR 3.4.5.6
HEAD FFC HARNESS ASSY,ASP 3.4.5.7
TUBE ASSY TUBE,SUPPLY,ASSY,ASP 3.4.5.8
CR UNIT CR ASSY.,A ASP. 3.4.5.9
OIL PAD HOLDER OIL PAD ASSY ESL,ASP 3.4.5.10
PUMP CAP ASSY
MAINTENANCE ASSY
ESL,ASP
3.4.5.11
CLOTH WIPER CARRIAGE
ASSY
CLOTH WIPER CASSETTE
ASSY ESL,ASP
3.4.5.12
DUCT TUBE ASSY TUBE,INK EJ,HOME,ASP 3.4.5.13
BUFFR ASSY BUFFER ASSY HOME ESL,ASP 3.4.5.14
CIRCULATION PUMP ASSY
BUFFER ASSY FULL,B
ESL,ASP
3.4.5.15
LEFT INK HOLDER ASSY
INK HOLDER ASSY FULL
ESL,ASP
3.4.5.16
RIGHT INK HOLDER ASSY INK HOLDER ASSY ESL,ASP 3.4.5.17
INK EJ ASSY TUBE,INK EJ,FULL,I ASP 3.4.5.18
Table 6-1. Conversion Table
Part name used in this manual ASP part name
Ref.
(Ch3
sec.No.)
