SC-F2000 Revision C
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 80
Confidential
3.4.3.8 FRONT SUB COVER
1. Remove the four screws, and remove the FRONT SUB COVER.
A) Silver M3x8 Cup S-tite screw: 4 pcs
Figure 3-23. Removing the FRONT SUB COVER
A
FRONT SUB COVER
A
A
A
