SC-F2000 Revision C
ADJUSTMENT Ink Supply Related Checks and Adjustments 249
Confidential
[Blue]: Button or menu name on the program screen / [Black]: Button or menu name on the operation panel of the printer
4.12.2 Tube Inner Cleaning
THINGS TO PREPARE
Cleaning Cartridge
EXECUTION MODE
Normal Mode
PROCEDURE
1. Turn the printer ON.
2. Start the Service Program and select [Tube inner cleaning].
3. Click [RUN]. An explanatory dialog box is displayed.
4. Clean the tubes following the dialog instructions.
5. The printer is turned OFF automatically.
6. Confirm the tube is filled with cleaning liquid.
Figure 4-50. [Tube inner cleaning] Screen
Time required for tube inner cleaning: about 35 minutes
To Next Page
