SC-F2000 Revision C
ADJUSTMENT Head Related Checks and Adjustments 234
Confidential
[Blue]: Button or menu name on the program screen / [Black]: Button or menu name on the operation panel of the printer
4.11 Head Related Checks and Adjustments
4.11.1 Tube Inner Pressure Reduction
EXECUTION MODE
Normal Mode
PROCEDURE
1. Turn the printer ON.
2. Start the Service Program and select [Tube inner pressure reduction].
3. Click [RUN].
The pressure inside the ink flow paths will be reduced.
Figure 4-32. [Tube inner pressure reduction] Screen
4. When pressure reduction is completed, the printer is turned OFF automatically.
After the printer is recovered from the depressurized state,
perform CL3 a few times.
To Next Page
