Disassembly and Assembly
Rev. A
3-2
9
ASF Tarnsmission Gear Set
Gear (PF Roller)
Bushing
Edge Guide
PF Roller
Bushing
E-ring
Paper Load Shaft
Figure 3-26. Paper Load Roller Removal
