 Note the direction in which the paper load gear and the gear (29) are engaged. (Refer to the
figure below.)
 Do not touch the gear teeth with your bare hands. Damaged gear may lose accuracy in paper
feeding.
WORK POINT
Gear 29
(ASF Transmission Gear Set)
Gear (PF Roller)
Figure 3-27. Gear Engagement
