Epson Stylus Color 740 Service Manual

EPSON Stylus COLOR 440, 640, and 740 Appendix
156
Stylus Color 440/640 EEPROM Address Map (Continued)
Address Explanation Setting
QPIT
Settings
Factory
Settings
0CH Stylus Color 440
Reserved
00H (
∗
1)
Stylus Color 640
Head actuator
rank ID for VhM
10H (
∗
1)
0DH Stylus Color 440
Reserved
00H —
Stylus Color 640
Head actuator
rank ID for VhMS
00H (
∗
1)
0EH Reserved 00H —
0FH Reserved 00H —
10H Password 1 5AH —
11H 0FH —
12H Custom EEPROM
sub number
00H 00H
13H 00H 00H
14H 00H 00H
15H 00H 00H
16H Reserved 00H —
17H Reserved 00H —
18H CPSI password 00H 00H
19H 00H 00H
1AH 00H 00H
1BH 00H 00H
1CH CPSI flags bit 7: CPSI license
0: Disable, 1: Enable
bit 6: CPSI Font license
0: Disable, 1: Enable
00H 00H
1DH Reserved 00H —
1EH Reserved 00H —
1FH EEPROM
Revision
42H —
.
Stylus Color 440/640 EEPROM Address Map (Continued)
Address Explanation Setting
QPIT
Settings
Factory
Settings
20H Password 2 5AH —
21H 0FH —
22H Interface selection 0: Auto, 1: Parallel
2: Serial
00H 00H (
∗
2)
23H Interface wait time 0 to 255 (by second) 0AH 0AH
24H Parallel I/F speed 0: High speed 1: Normal 00H 00H
25H Stylus Color 440
Reserved
00H —
Stylus Color 640
Font
0: Couier 00H 00H
26H Stylus Color 440
Reserved
00H —
Stylus Color 640
Pitch
0: 10 cpi 00H 00H
27H Stylus Color 440
Print direction
control
0: Bi-D
1: Uni-D
2: Auto
02H 02H
Stylus Color 640
Print direction
control
2: Auto 02H 02H
28H Stylus Color 440
CG table
0: PC437 1: PC850 00H (
∗
1)
Stylus Color 640
CG table
0: PC437 1: PC850 08H 00H
29H Reserved 00H —
2AH Auto LF/Network
I/F mode
bit 1: Network I/F mode
(0=off, 1=on)
bit 0: Auto line feed
(0=off, 1=on)
00H 00H
