48 Setup
Customized values
*1: Not available for TM-L90 other than 4** models
*2: Not available for TM-L90 4** models
*3: Selectable 38, 58, 60, 70, 80 mm only
Note:
❏ The maximum print speed is available for only the one-part energizing mode. However, if the print
duty is too high in the one-part energizing mode, the printer will automatically reduce the printing
speed.
❏ The four-part energizing mode reduces power consumption.
❏ The print width can be set in 43 ways with 1 mm pitches in the range from 38 mm to 80 mm.
However, it cannot be set in the range from 71 mm to 79 mm.
Item
Option
(underlined: initial setting)
Msw
Setting
utility
Msw
Setting
Mode
NV user memory capacity 1KB
, 64KB, 128KB, 192KB ✓
NV graphics memory capacity None, 64KB, 128KB, 192KB, 256KB, 320KB,
384KB
✓
Print density 70%, 75%, 80%, 85%, 90%, 95%, 100%, 105%,
110%
, 115%, 120%, 125%, 130%, 135%, 140%
✓✓
Print speed Level 1 (Slow) - Level 6
- Level 9 (Fast) ✓✓
*1
Default character code table
*1
Initial setting: Page 0: PC437 (USA, Standard
Europe)
✓✓
Default international character
*1
Initial setting: USA ✓✓
Selection of the interface
*1
Auto, UIB, Built-in USB ✓✓
Number of divisions of thermal head
energizing
1
, 2, 3, 4 ✓
Automatic replacement of Font A
*1
Do not replace, Font B ✓✓
Automatic replacement of Font B
*1
Do not replace, Font A ✓✓
Paper selection
(monochrome or two-color)
*2
Monochrome, two-color ✓✓
Paper width 38 mm - 80 mm
(1 mm pitches) ✓✓
*3
Black-color density in two-color
printing
*2
Light, Medium, Dark ✓
Buzzer control
*1
Buzzer selection: Internal, Option, Disable
Buzzer frequency: Continuous, 1 time, No
sound
Sound pattern: Pattern A, B, C, D, or E
(Refer to "Setting items of TM-L90 4** models"
on page 121, about the initial settings.)
✓✓
To Next Page
