Page 111 of 159
Figure 82. Profile Limits Settings Panel
In SSM mode we are using the same profile limits as we are using in normal mode.
13.8 X-B Settings
The X-B panel displays the currently selected X-B constants. Change the values as needed, then click
or tap Save to save the new values and return to the Settings panel, or select Back to discard any
changes and return to the Settings panel.
The following X-B settings are available:
• Lower and upper limit – A parameter is usable in X-B statistics if its value is between these
criteria
• Target – the start value of the first batch in the X-B algorithm
• Action limit (%) - maximum percent deviation of the running average values from the target
value. The user needs to check the X-B diagrams regularly as no action is performed by the
software if the action limit is reached
