9.8.3 Export
The database export panel allows you to select a directory location to store records in a
selection for backup or reference purposes. To back up all records in the database, first use
the Select by function to select all records in the database and export them using the export
function.
Clicking or tapping the ‘Export’ button displays the database export panel.
Figure 65. Directory Panel for Data Storage
Introduce a USB storage device (USB hard drive, memory stick, etc.) into an available USB
port on the back panel of the ‘ELite 5’ analyzer. Select the directory to store the exported
data and press the ‘Ok’ button to start the export.
The file format of exported data is an internal format, and can only be read and interpreted by
the ‘ELite 5’ analyzer using the Import function. Each database record is stored as an
individual file with a ‘.rp’ extension.
9.8.4 Send to LIS
The ‘Send to LIS’ button immediately transmits selected database records to the external LIS
according to your LIS settings.
9.8.5 Save Tab File
The Save tab file function is used to archive database data to a tab separated text file. The
‘Save tab file’ button displays a directory panel like Figure , except that the file saved in the
