A. 7
S.SCL nO
SC.dP ——. (No decimal figure)
SC.E.L 0
SC.E.H 100
SC.A.C bEFr
Configuration group 4 [C.Gxx]
PARAM. VALUE NOTES
Sñ.Fn Enb
Cn.tP PId
ñAn.F Enb
Añ.UL buñ.
ñ.A.t.t buñ.
St.Fn Cnd.b
SF.Cn Std.
SF.UL 0.0
Configuration group 5 [C.Hxx]
PARAM. VALUE NOTES
d1.Fn SP1.2
d1.St CLSd
d2.Fn SP3.4
d2.St CLSd
d3.Fn ñ.rSt
d3.St CLSd
E1.Fn ñ.In.E
E1.St CLSd
E2.Fn ñEA.E
E2.St CLSd
E3.Fn Au.ñA
E3.St CLSd
E4.Fn SP.L.r
E4.St CLSd
Configuration group 6 [C.Ixx]
PARAM. VALUE NOTES
G.brG DEv
O.brG P.Out
brG.L -100 °C
brG.H 1370 °C
brG.d 10 °C
SP.AL n.ALG
SP.dS OP.SP
Sr.bH bAL
SS.tr -100 °C
t.out tñ.10
Fd.Fn nonE If option is not mounted or main
control output is linear
ñC.On If option is mounted
Fd.HS 25
