A. 8
Fd.Ou nonE
TABLE 2
Configuration group 1 [C.dxx]
PARAM. VALUE NOTES
Ln.Fr 60 Hz
ñ.In.t 18 (TC K with °F)
ñ.In.d ——. (No decimal figure)
ñ.In.S dIS Disabled
ñ.In.L -150 °F
ñ.In.H 2500 °F
OFSt 0 °F
dS.FL 0 (No filter)
A.In.F RSP Remote set point
A.In.t 4-20 mA
A.In.L 32 °F
A.In.H 1832 °F
A.I.FL 0 (No filter)
A.I.Añ norñ
A.I.Sc nonE
L.r.O.ñ n.ALG
Configuration group 2 [C.Exx]
PARAM. VALUE NOTES
O1.Fn ñAin If servo motor drive is not mounted
ALr.1 If servo motor drive or linear output
are mounted
O2.Fn ALr.2
O3.Fn nonE If option is not mounted
ñC.Sñ If servo control motor drive is
mounted
ALr.3 If option is mounted
O4.Fn nonE If option is not mounted
Alr.4 If option is mounted
Sñ.tP CLSd If feedback circuitry is mounted
OPEn If feedback circuitry is not mounted
FEEd no.Fb
O5.Fn nonE If option is not mounted
ñAin If option is mounted
O5.rn 4-20 4-20 mA
O5.Lr 32 °F
O5.Hr 1832 °F
O5.FL 0 No filter
O6.Fn nonE If option is not mounted
PV.rt If option is mounted
O6.rn 4-20 4-20 mA
O6.Lr 32 °F
