Controlling Your Lighting System 23
Keypad
The keypad is opened by going to Controls>Keypad. This provides classic lighting control of channels
and levels via a numeric keypad entry.
Note: Colors, Effects, Media, and Parameter settings must be controlled on their respective
screens.
Available Buttons
+ (Plus)
- (Minus)
Thru
Full
@ (At)
..<<..(Backspace)
Enter
Keypad, Plus
Adds a channel to the selection set.
For Example:
1 Thru 10 + 20 Enter - creates a set of eleven channels: 1-10 plus 20.
Keypad, Minus
Removes a channel from the selection set.
For Example:
1 Thru 10 - 7 Enter - creates a set of nine channels: 1-6 plus 8-10.
Keypad, Thru
Selects a range of channels.
For Example:
1 Thru 10 Enter - creates a set of ten channels: 1-10.
Keypad, Full
Sets the selected channels to full intensity.
To apply the chosen intensity, you must complete the command with the Enter key.
For Example:
1 @ Full Enter - sets channel one to full intensity.
Keypad, @ (at level)
Sets the selected channels to a level specified in percent % from 0 to 100.
To apply the chosen intensity, you must complete the command with the Enter key.
For Example:
1 + 5 @ 70 Enter - sets channels one and five to 70% intensity.
