HMG-838PT & HMG-838EPT Web Configuration 10-10
MLD Snooping Group Information:
VLAN ID: Display the VLAN ID of the group.
Groups: Display the group address.
Port Members: Ports that belong to this group.
Note: The maximum number of IGMP Snooping groups can be learned is 32.
10-2.6 IPv6 SFM Information
MLD SFM Information:
VLAN ID: Display the VLAN ID of the group.
Group: Display the IP address of a multicast group.
Port: The switch port number.
Mode: The filtering mode maintained per VLAN ID, port number and group address.
Source Address: The source IP address available for filtering.
Type: Display either Allow or Deny type.
Hardware Filter/Switch: Indicates whether the data plane destined to the specific group address from the source
IPv4 address can be handled by the chip or not.
