MAC Table
HMG-838PT & HMG-838EPT Web Configuration 12-2
switch via the serial interface.
Static MAC Table Configuration
Static MAC Table Configuration: This table is used to manually set up static MAC entries. The total entries that
can be entered are 64.
Delete: Delete this MAC address entry.
VLAN ID: Specify the VLAN ID for this entry.
Port Members: Check or uncheck the ports. If the incoming packet has the same destination MAC address
as the one specified in VID, it will be forwarded to the checked port directly.
12-2 MAC Address Table
The MAC Address Table shows both static and dynamic MAC addresses learned from CPU or switch ports. You can
enter the starting VLAN ID and MAC addresses to view the desired entries.
MAC Address Table:
Type: Display whether the learned MAC address is static or dynamic.
VLAN ID: The VLAN ID associated with this entry.
MAC Address: The MAC address learned on CPU or certain ports.
Port Members: Ports associated with this entry.
