Operating Instructions
Modular Safety Control System MSC
EN
CURTAIN selected
S1 S2 Input S3 S4 Muting
0 0 1 0 0 0
1 0 1 0 0 0
1 1 1 0 0 1
Muting activated
1 1 X 0 0 1
1 1 X 1 0 1
1 1 X 1 1 1
0 1 X 1 1 1
0 0 0 1 1 1
0 0 1 1 1 0
0 0 1 0 1 0
0 0 1 0 0 0
Table 72: Status table sequential muting with CURTAIN selected
SENSOR selected
S1 S2 Input S3 S4 Muting
0 0 1 0 0 0
1 0 1 0 0 0
1 1 1 0 0 1
Muting activated
1 1 X 0 0 1
1 1 X 1 0 1
1 1 X 1 1 1
0 1 X 1 1 1
0 0 0 1 1 1
0 0 1 1 1 1
0 0 1 0 1 0
0 0 1 0 0 0
Table 73: Status table sequential muting with SENSOR selected
Blind Time: Only with "Muting Closing = Curtain": Should be selected if, for instance, it is known that after the end of
the muting, objects may protrude beyond the pallet and may occupy the light grid, as a result the INPUT input is set to "0"
(FALSE). During the blind time the input remains "1" (TRUE). The blind time can be between 250 ms and 1 s.
