8.1.3. Housing
Description Electronics housing, 24-pin max.
Material of housing Polyamide
Degree of protection, housing IP20
Degree of protection, terminal blocks IP 2X
Fastening Quick-release connection to rail as per EN 60715
Dimensions (H x W x D) in mm 108 x 22.5 x 114.5
8.1.4. Module MSC-CB
PFH
D
(EN IEC 61508:2010) 6.06 E-9
Operating voltage 24 VDC ±20 %
Power dissipation 3 W max.
Module enable (no./description) 2/ PNP active high "type B" as per EN 61131-2
Digital INPUTS (no./description) 8/ PNP active high as per EN 61131-2
INPUT_FBK/RESTART (no./description) 2/ EDM control/automatic or manual operation possible using RESTART button
Test OUTPUT (no./description) 4/ for checking for short circuits, overload states
Digital OUTPUTS (no./description) 2/ programmable – PNP active high
OSSD (no./description) 2 pairs/static safety outputs – PNP active high 400 mA at 24 VDC max.
Slot for the M-A1 Available
Connection to PC USB 2.0 (Hi Speed) – cable length max.: 3 m
Connection to extension module Via proprietary 5-way MSCB from EUCHNER
8.1.5. Module FI8FO2
PFH
D
(EN IEC 61508:2010) 5.72 E-9
Operating voltage 24 VDC ±20 %
Power dissipation 3 W max.
Digital INPUTS (no./description) 8/ PNP active high as per EN 61131-2
Test OUTPUT (no./description) 8/ for checking for short circuits, overload states
Digital OUTPUTS (no./description) 2/ programmable – PNP active high
OSSD (no./description) 2 pairs/static safety outputs – PNP active high 400 mA at 24 VDC max.
Connection to MSC-CB Via proprietary 5-way MSCB from EUCHNER
8.1.6. Modules FI8 – FI16
Module FI8 FI16
PFH
D
(EN IEC 61508:2010) 4.45 E-9 4.94 E-9
Operating voltage 24 VDC ±20 %
Power dissipation 3 W max.
Digital INPUTS (no./description)
8 16
PNP active high as per EN 61131-2
Test OUTPUT (no./description) 4/ for checking for short circuits, overload states
Connection to MSC-CB Via proprietary 5-way bus MSC from EUCHNER
8.1.7. Module FM4
PFH
D
(EN IEC 61508:2010) 5.56 E-9
Operating voltage 24 VDC ±20 %
Power dissipation 3 W max.
Digital INPUTS (no./description) 12/ PNP active high as per EN 61131-2
Test OUTPUT (no./description) 8/ for checking for short circuits, overload states
Connection to MSC-CB Via proprietary 5-way bus MSCB from EUCHNER
