EUCHNER MSC - Module FI8; Module FM4

Operating Instructions
Modular Safety Control System MSC
18
(Translation of the original operating instructions) 2121331-04-04/19
5.3.3.4. Module FI8
TERMINAL SIGNAL TYPE DESCRIPTION VERSION
1 24 VDC - Power supply 24 VDC -
2 NODE_SEL0 Input
Node selection
Input ("type B" as per EN 61131-2)
3 NODE_SEL1 Input Input ("type B" as per EN 61131-2)
4 GND - Power supply 0 VDC -
5 INPUT1 Input Digital input 1 Input as per EN 61131-2
6 INPUT2 Input Digital input 2 Input as per EN 61131-2
7 INPUT3 Input Digital input 3 Input as per EN 61131-2
8 INPUT4 Input Digital input 4 Input as per EN 61131-2
9 OUT_TEST1 Output Output for short circuit detection PNP active high
10 OUT_TEST2 Output Output for short circuit detection PNP active high
11 OUT_TEST3 Output Output for short circuit detection PNP active high
12 OUT_TEST4 Output Output for short circuit detection PNP active high
13 INPUT5 Input Digital input 5 Input as per EN 61131-2
14 INPUT6 Input Digital input 6 Input as per EN 61131-2
15 INPUT7 Input Digital input 7 Input as per EN 61131-2
16 INPUT8 Input Digital input 8 Input as per EN 61131-2
Table 4: Module FI8
5.3.3.5. Module FM4
TERMINAL SIGNAL TYPE DESCRIPTION VERSION
1 24 VDC - Power supply 24 VDC -
2 NODE_SEL0 Input
Node selection
Input ("type B" as per EN 61131-2)
3 NODE_SEL1 Input Input ("type B" as per EN 61131-2)
4 GND - Power supply 0 VDC -
5 INPUT1 Input Digital input 1 Input as per EN 61131-2
6 INPUT2 Input Digital input 2 Input as per EN 61131-2
7 INPUT3 Input Digital input 3 Input as per EN 61131-2
8 INPUT4 Input Digital input 4 Input as per EN 61131-2
9 OUT_TEST1 Output Output for short circuit detection PNP active high
10 OUT_TEST2 Output Output for short circuit detection PNP active high
11 OUT_TEST3 Output Output for short circuit detection PNP active high
12 OUT_TEST4 Output Output for short circuit detection PNP active high
13 INPUT5 Input Digital input 5 Input as per EN 61131-2
14 INPUT6 Input Digital input 6 Input as per EN 61131-2
15 INPUT7 Input Digital input 7 Input as per EN 61131-2
16 INPUT8 Input Digital input 8 Input as per EN 61131-2
17 OUT_TEST5 Output Output for short circuit detection PNP active high
18 OUT_TEST6 Output Output for short circuit detection PNP active high
19 OUT_TEST7 Output Output for short circuit detection PNP active high
20 OUT_TEST8 Output Output for short circuit detection PNP active high
21 INPUT9 Input Digital input 9 Input as per EN 61131-2
22 INPUT10 Input Digital input 10 Input as per EN 61131-2
23 INPUT11 Input Digital input 11 Input as per EN 61131-2
24 INPUT12 Input Digital input 12 Input as per EN 61131-2
Table 5: Module FM4
