5.3.3.6. Module FI16
TERMINAL SIGNAL TYPE DESCRIPTION VERSION
1 24 VDC - Power supply 24 VDC -
2 NODE_SEL0 Input
Node selection
Input ("type B" as per EN 61131-2)
3 NODE_SEL1 Input Input ("type B" as per EN 61131-2)
4 GND - Power supply 0 VDC -
5 INPUT1 Input Digital input 1 Input as per EN 61131-2
6 INPUT2 Input Digital input 2 Input as per EN 61131-2
7 INPUT3 Input Digital input 3 Input as per EN 61131-2
8 INPUT4 Input Digital input 4 Input as per EN 61131-2
9 OUT_TEST1 Output Output for short circuit detection PNP active high
10 OUT_TEST2 Output Output for short circuit detection PNP active high
11 OUT_TEST3 Output Output for short circuit detection PNP active high
12 OUT_TEST4 Output Output for short circuit detection PNP active high
13 INPUT5 Input Digital input 5 Input as per EN 61131-2
14 INPUT6 Input Digital input 6 Input as per EN 61131-2
15 INPUT7 Input Digital input 7 Input as per EN 61131-2
16 INPUT8 Input Digital input 8 Input as per EN 61131-2
17 INPUT9 Output Digital input 9 Input as per EN 61131-2
18 INPUT10 Output Digital input 10 Input as per EN 61131-2
19 INPUT11 Output Digital input 11 Input as per EN 61131-2
20 INPUT12 Output Digital input 12 Input as per EN 61131-2
21 INPUT13 Input Digital input 13 Input as per EN 61131-2
22 INPUT14 Input Digital input 14 Input as per EN 61131-2
23 INPUT15 Input Digital input 15 Input as per EN 61131-2
24 INPUT16 Input Digital input 16 Input as per EN 61131-2
Table 6: Module FI16
