9.1.10.2. Printing project report
The system layout can be printed together with the properties of the individual blocks ( button on the default toolbar).
Figure 50: EUCHNER Safety Designer, project report
WARNING
Ì This definition of the PL and the other related parameters as per EN ISO 13849-1 relate only to
the functions that have been implemented by EUCHNER Safety Designer in the MSC system; here
it is assumed that the configuration has been undertaken correctly.
Ì The data for all devices connected to the MSCB in the application must be taken into account in
the actual PL for the entire application and the related parameters.
Ì This task is only allowed to be undertaken by the design engineer or the installer.
