EUCHNER MSC - Module O8; Module O16

Operating Instructions
Modular Safety Control System MSC
24
(Translation of the original operating instructions) 2121331-04-04/19
5.3.4.3. Module O8
Pin SIGNAL TYPE DESCRIPTION VERSION
1 24 VDC - Power supply 24 VDC -
2 NODE_SEL0 Input
Node selection
Input ("type B" as per EN 61131-2)
3 NODE_SEL1 Input Input ("type B" as per EN 61131-2)
4 GND - Power supply 0 VDC -
5 24 VDC STATUS 1-8 -
Power supply 24 VDC
monitoring outputs 1-8
-
6 - - - -
7 - - - -
8 - - - -
9 SYS_STATUS1 Output Programmable digital output 1 PNP active high
10 SYS_STATUS2 Output Programmable digital output 2 PNP active high
11 SYS_STATUS3 Output Programmable digital output 3 PNP active high
12 SYS_STATUS4 Output Programmable digital output 4 PNP active high
13 SYS_STATUS5 Output Programmable digital output 5 PNP active high
14 SYS_STATUS6 Output Programmable digital output 6 PNP active high
15 SYS_STATUS7 Output Programmable digital output 7 PNP active high
16 SYS_STATUS8 Output Programmable digital output 8 PNP active high
Table 13: Module O8
5.3.4.4. Module O16
Pin SIGNAL TYPE DESCRIPTION VERSION
1 24 VDC - Power supply 24 VDC -
2 NODE_SEL0 Input
Node selection
Input ("type B" as per EN 61131-2)
3 NODE_SEL1 Input Input ("type B" as per EN 61131-2)
4 GND - Power supply 0 VDC -
5 24 VDC STATUS 1-8
Power supply 24 VDC
programmable digital output 1-8
6 24 VDC STATUS 9-16
Power supply 24 VDC
programmable digital output 9-16
7 - - - -
8 - - - -
9 SYS_STATUS1 Output Programmable digital output 1 PNP active high
10 SYS_STATUS2 Output Programmable digital output 2 PNP active high
11 SYS_STATUS3 Output Programmable digital output 3 PNP active high
12 SYS_STATUS4 Output Programmable digital output 4 PNP active high
13 SYS_STATUS5 Output Programmable digital output 5 PNP active high
14 SYS_STATUS6 Output Programmable digital output 6 PNP active high
15 SYS_STATUS7 Output Programmable digital output 7 PNP active high
16 SYS_STATUS8 Output Programmable digital output 8 PNP active high
17 SYS_STATUS9 Output Programmable digital output 9 PNP active high
18 SYS_STATUS10 Output Programmable digital output 10 PNP active high
19 SYS_STATUS11 Output Programmable digital output 11 PNP active high
20 SYS_STATUS12 Output Programmable digital output 12 PNP active high
21 SYS_STATUS13 Output Programmable digital output 13 PNP active high
22 SYS_STATUS14 Output Programmable digital output 14 PNP active high
23 SYS_STATUS15 Output Programmable digital output 15 PNP active high
24 SYS_STATUS16 Output Programmable digital output 16 PNP active high
Table 14: Module O16
