EUCHNER MSC - Module AZ-FO4; Module AZ-FO4 O8

23
2121331-04-04/19 (Translation of the original operating instructions)
Operating Instructions
Modular Safety Control System MSC
EN
5.3.4.1. Module AZ-FO4
TERMINAL SIGNAL TYPE DESCRIPTION VERSION
1 24 VDC - Power supply 24 VDC -
2 NODE_SEL0 Input
Node selection
Input ("type B" as per EN 61131-2)
3 NODE_SEL1 Input Input ("type B" as per EN 61131-2)
4 GND - Power supply 0 VDC -
5 REST_FBK1 Input Feedback loop/restart 1 Input as per EN 61131-2
6 REST_FBK2 Input Feedback loop/restart 2 Input as per EN 61131-2
7 REST_FBK3 Input Feedback loop/restart 3 Input as per EN 61131-2
8 REST_FBK4 Input Feedback loop/restart 4 Input as per EN 61131-2
9 A_NO1 Output
Normally open contact channel 1
10 B_NO1 Output
11 A_NO2 Output
Normally open contact channel 2
12 B_NO2 Output
13 A_NO3 Output
Normally open contact channel 3
14 B_NO3 Output
15 A_NO4 Output
Normally open contact channel 4
16 B_NO4 Output
Table 11: Module AZ-FO4
5.3.4.2. Module AZ-FO4O8
TERMINAL SIGNAL TYPE DESCRIPTION VERSION
1 24 VDC - Power supply 24 VDC -
2 NODE_SEL0 Input
Node selection
Input ("type B" as per EN 61131-2)
3 NODE_SEL1 Input Input ("type B" as per EN 61131-2)
4 GND - Power supply 0 VDC -
5 REST_FBK1 Input Feedback loop/restart 1 Input as per EN 61131-2
6 REST_FBK2 Input Feedback loop/restart 2 Input as per EN 61131-2
7 REST_FBK3 Input Feedback loop/restart 3 Input as per EN 61131-2
8 REST_FBK4 Input Feedback loop/restart 4 Input as per EN 61131-2
9 A_NO1 Output
Normally open contact channel 1
10 B_NO1 Output
11 A_NO2 Output
Normally open contact channel 2
12 B_NO2 Output
13 A_NO3 Output
Normally open contact channel 3
14 B_NO3 Output
15 A_NO4 Output
Normally open contact channel 4
16 B_NO4 Output
17 SYS_STATUS1 Output Programmable digital output 1 PNP active high
18 SYS_STATUS2 Output Programmable digital output 2 PNP active high
19 SYS_STATUS3 Output Programmable digital output 3 PNP active high
20 SYS_STATUS4 Output Programmable digital output 4 PNP active high
21 SYS_STATUS5 Output Programmable digital output 5 PNP active high
22 SYS_STATUS6 Output Programmable digital output 6 PNP active high
23 SYS_STATUS7 Output Programmable digital output 7 PNP active high
24 SYS_STATUS8 Output Programmable digital output 8 PNP active high
Table 12: Module AZ-FO4O8
