8.4.11. Modules SPM0, SPM1, SPM2 (Figure 37)
MEANING
LED
RECTIFICATION MEASURE
RUN
GREEN
IN FAIL
RED
EXT FAIL
RED
SEL
ORANGE
ENC*
YELLOW
PROX
YELLOW
SH
YELLOW
Internal error OFF
Flashes 2 or
3 times
OFF
Indicates
the physical
address of the
module
OFF OFF OFF
Ì Send module to EUCHNER
for repair
Compatibility error OFF
Flashes 5
times
OFF
Flashes 5
times
Flashes 5
times
Flashes 5
times
Ì Firmware version not com-
patible with MSC-CB. Send to EUCHNER for firmware upgrade.
Internal encoder error
OFF
Flashes 3
times
OFF
Flashes 3
times
OFF OFF
Ì Replace encoder Ì Send to EUCHNER for repair
Internal proximity switch error
OFF
Flashes 3
times
OFF
Flashes 3
times
Ì Replace proximity switch Ì Send to EUCHNER for repair
Internal node detec- tion error
OFF
Flashes 3
times
OFF
Flashes 3
times
OFF OFF OFF
Ì Send module to EUCHNER
for repair
Extension module of the same type with the same address detected
OFF
Flashes 5
times
Flashes 5
times
OFF OFF OFF
Ì Change address of the mod-
ule (see section NODE_SEL)
Encoder not connect- ed, but requested by configuration
OFF OFF
Flashes 3
times**
Flashes 3
times**
OFF OFF
Ì Check connection and power
supply for the encoder/prox- imity switch
Ì Check input frequency (in
range)
Proximity switch not connected, but requested by config- uration
OFF OFF
Flashes 3
times**
OFF
Flashes 3
times**
OFF
* IF SPM0 MODULE NOT FITTED ** IF ERROR ON A SINGLE CHANNEL, THE FOLLOWING ERROR INFORMATION IS INDICATED IN SUCCESSION:
FIRST THE ERROR, THEN THE ERRONEOUS CHANNEL.
Table 56: Troubleshooting SPM0, SPM1, SPM2
Figure 37: SPM1, SPM2
