5.3.3.2. RESTORE function
If the module MSC-CB is faulty, it can be replaced with a new module. As the entire configuration is saved on the M-A1 memory
card, it is only necessary to insert this card in the new module and switch on the MSC system, the backed up configuration
will then be loaded immediately. In this way interruptions in operation can be reduced to a minimum.
Important!
Ì The LOAD and RESTORE functions can be deactivated using the software (see Figure 44: EUCH-
NER Safety Designer, selecting extension module on page 68).
Ì The extension modules must be assigned addresses during installation so they can be used (see
NODE_SEL).
WARNING
Ì Each time M-A1 is used, it is to be carefully checked whether the configuration selected is the con-
figuration prepared for this specific system. Undertake a complete function check on the system
comprising the MSC and all devices connected to it (see section "CHECKING the system" Page
80).
5.3.3.3. Module FI8FO2
TERMINAL SIGNAL TYPE DESCRIPTION ACTION
1 24 VDC - Power supply 24 VDC -
2 NODE_SEL0 Input
Node selection
Input ("type B" as per EN 61131-2)
3 NODE_SEL1 Input Input ("type B" as per EN 61131-2)
4 GND - Power supply 0 VDC -
5 OSSD1_A Output
Safety output 1
PNP active high
6 OSSD1_B Output PNP active high
7 RESTART_FBK1 Input Feedback loop/restart 1 Input as per EN 61131-2
8 OUT_STATUS1 Output Programmable digital output PNP active high
9 OSSD2_A Output
Safety output 2
PNP active high
10 OSSD2_B Output PNP active high
11 RESTART_FBK2 Input Feedback loop/restart 2 Input as per EN 61131-2
12 OUT_STATUS2 Output Programmable digital output PNP active high
13 OUT_TEST1 Output Output for short circuit detection PNP active high
14 OUT_TEST2 Output Output for short circuit detection PNP active high
15 OUT_TEST3 Output Output for short circuit detection PNP active high
16 OUT_TEST4 Output Output for short circuit detection PNP active high
17 INPUT1 Input Digital input 1 Input as per EN 61131-2
18 INPUT2 Input Digital input 2 Input as per EN 61131-2
19 INPUT3 Input Digital input 3 Input as per EN 61131-2
20 INPUT4 Input Digital input 4 Input as per EN 61131-2
21 INPUT5 Input Digital input 5 Input as per EN 61131-2
22 INPUT6 Input Digital input 6 Input as per EN 61131-2
23 INPUT7 Input Digital input 7 Input as per EN 61131-2
24 INPUT8 Input Digital input 8 Input as per EN 61131-2
Table 3: Module FI8FO2
