15
2121331-04-04/19 (Translation of the original operating instructions)
Operating Instructions
Modular Safety Control System MSC
EN
5.3.1. Information in relation to connecting cables
NOTICE
Ì Connection cross-section range: AWG 12 – 30, (single conductor/multiple conductor) (UL).
Ì Only use copper wires (Cu) for 60/75 °C.
Ì It is recommended to use separate power supplies for the safety module and for other electrically
powered devices (electric motors, inverters, frequency converters) or other sources of interfer-
ence.
Ì Cables for connections with a length of more than 50 m must have a cross-section of at least
1mm
2
(AWG16).
5.3.1.1. Base unit MSC-CB
The connections for each module in the MSC system are listed in the table below:
TERMINAL SIGNAL TYPE DESCRIPTION VERSION
1 24 VDC - Power supply 24 VDC -
2 MASTER_ENABLE1 Input Base unit enable 1 Input ("type B" as per EN 61131-2)
3 MASTER_ENABLE2 Input Base unit enable 2 Input ("type B" as per EN 61131-2)
4 GND - Power supply 0 VDC -
5 OSSD1_A Output
Safety output 1
PNP active high
6 OSSD1_B Output PNP active high
7 RESTART_FBK1 Input Feedback loop/restart 1 Input as per EN 61131-2
8 OUT_STATUS1 Output Programmable digital output PNP active high
9 OSSD2_A Output
Safety output 2
PNP active high
10 OSSD2_B Output PNP active high
11 RESTART_FBK2 Input Feedback loop/restart 2 Input as per EN 61131-2
12 OUT_STATUS2 Output Programmable digital output PNP active high
13 OUT_TEST1 Output Output for short circuit detection PNP active high
14 OUT_TEST2 Output Output for short circuit detection PNP active high
15 OUT_TEST3 Output Output for short circuit detection PNP active high
16 OUT_TEST4 Output Output for short circuit detection PNP active high
17 INPUT1 Input Digital input 1 Input as per EN 61131-2
18 INPUT2 Input Digital input 2 Input as per EN 61131-2
19 INPUT3 Input Digital input 3 Input as per EN 61131-2
20 INPUT4 Input Digital input 4 Input as per EN 61131-2
21 INPUT5 Input Digital input 5 Input as per EN 61131-2
22 INPUT6 Input Digital input 6 Input as per EN 61131-2
23 INPUT7 Input Digital input 7 Input as per EN 61131-2
24 INPUT8 Input Digital input 8 Input as per EN 61131-2
Table 2: Base unit MSC-CB
