CP-2116E
Remote Control Panel
Revision 1.2 Page - 25
5.2.3. Services Page
The Services page enables the user to create a service or edit an existing service, which can be
loaded onto the CP-2116E control panel. The user can define the frame, pin point a card in a
particular slot, and assign an input using the Services page.
The services that currently exist will be listed in the far left column as illustrated in Figure 5-11.
Figure 5-11: Services List
The user can add, copy, or remove a service using the Service buttons listed in Table 5-2:
New Service
The New Service button e
nables the user to add and create a new
service. Selecting this button will open a new service page.
Duplicate
Services
The Duplicate Services
button enables the user to duplicate the
selected service. Select the service
that you wish to copy and then
press the Duplicate Services button to create a replica of that service.
Delete Services
The Delete Services button enables the user to completely remove the
currently selected service. Select the service that you wish to delete
and then press the Delete Services button to remove the template.
Table 5-2: Service Template Buttons
Once a service is selected or the user creates a new service, a new page will appear enabling the user
to customize the service.
