3.4 Brew Group Assembly
Brew Chamber
Cylinder
Piston
Coffee Spillway
Aluminum Frame
Wheel
Manufacturing Date
(on the back)
Funnel
Yoke
Reference Drawings
Crush hazard. Handle the brew group cautiously.
