www.cafection.com 800-561-6162
40
DS2212NSA Rev. 1 2023-04
SERVICE & INSTALLATION MANUAL - Symbol
6.6 System Tab
To access the screen below, tap in order on the top left, bottom left and bottom right corners of
the screen (see section6) and select the System tab.
6.6.1 Settings Sub Tab
1. This button is used to set the languages of the system and user interface. If the
language is changed, the recipes’ names will be reset to default values.
- The first dropdown menu is used to set the
main language, which will be used for both the
Service mode and the selection screen
- Activate the toggle bar to allow any user to switch
language directly from the selection screen.
- The second dropdown menu is used to set a
second language for the selection screen.
2. This field is used to set the quantity of drinks to be ordered before showing the "Rinse
Required Soon" alert. To disable this alert, set the value to zero (0).
3. This field is used to set the quantity of coffee drinks to brew before showing the "Waste
Bin Full" alert. To disable this alert, set the value to zero (0).
4. This button is used to set the color theme of the user
interface.
- Select desired theme color from the color palette
- Use the buttons to discard or save selection.
5. This toggle bar is used to lock recipes on the selection
screen when a rinse is due.
1615
10
11
12
1
2
5
4
7
3
6
8
13
14
9
Service Mode
