SERVICE & INSTALLATION MANUAL - Symbol
6.5.3 Brew Cycles Settings Sub Tab
1. This table is used to set the brew
cycles and extra grind time. Press
on the quantity to modify it and enter
the desired number of units using the
numeric keyboard.
2. This button is used to set all brew
cycles values back to factory settings.
3. These buttons are used to discard or
save any current modification.
The Symbol has 1 different brew cycles. The brew cycle is automatically selected in
accordance with the coffee and water quantities in the coffee-based recipe.
Pause1
First contact time between water and coffee grounds. To get more extraction, increase this
value. 20 units = 1 second.
Pause2
Second contact time between water and coffee grounds. To get more extraction, increase
this value. 20 units = 1 second.
Move 3
Position where the piston stops before dispensing the coffee into the cup.
This setting must be changed with care.
A setting too high will prematurely open the brew chamber, causing a mess of wet
coffee grounds inside the machine.
A setting too low will not pull all the coffee through the filter.
Pause3
Pause time before the brew chamber opens. If there are wet coffee grounds on the filter paper
at the end of the cycle, increasing this setting might solve the issue. 20 units = 1 second.
Pause4
Brew group drain time. This setting must be high enough to empty the brew group at the
end of the cycle. 20 units = 1 second.
This interface is used to set all coffee drinks’ brew cycles. There is no individual
setting table per recipe.
Service Mode
1
3
2
