83
www.cafection.com 800-561-6162
DS2212NSA Rev. 1 2023-04
SERVICE & INSTALLATION MANUAL - Symbol
Annex 1
ANNEX 1 CHUTE HOLE POSITION
BACK WALL
FRONT DOOR
CHUTE HOLE
CHUTE HOLE POSITION
SYMBOL
"HOLE EDGES SHOULD BE SEALED WITH SILICONE OR AN APPROPRIATE
SEALANT FOR PROTECTION AGAINST WATER DAMAGE"
Symbol 2023-03
13.56"
1.25"
16.13"
15.13"
5.19"
4.63"
6.00"
4.00"
15.13"
CHUTE HOLE
