35
www.cafection.com 800-561-6162
DS2212NSA Rev. 1 2023-04
SERVICE & INSTALLATION MANUAL - Symbol
6.5.2 Recipes Information Sub Tab
1. This drop-down menu is used to choose the recipe requiring modifications.
2. This field is used to set the recipe name that will be shown on the selection screen
under the beverage illustration.
If the language of the system is changed, the name of the recipes will be reset to
factory settings.
3. This checkbox is used to enable or disable the drink on the selection screen.
4. This section is used to enable or disable each size for the recipe.
Use the first text field to set the text displayed on the cup size buttons.
Use the second text field to set the price of the recipe for each size.
Get a sample of ingredients or the complete drink with the "Sample" button.
"
Get a Sample
"
Interface
A These buttons are used to get a sample of all the dry ingredients of the
tested recipe, in the desired strength.
Make sure to place a container
under ALL product dispensers used for the tested recipe.
B This button is used to get a sample of the recipe without the ingredients.
Make sure to place a recipient large enough under the dispensing
nozzle.
C These buttons are used to get a sample of the entire recipe, in the desired
strength.
Samples are not registered in the sales counters.
5. This switch is used to add the "Pick Me" tag over the beverage on the selection
screen.
6. The Liquids and Ingredients interface is used to customize the quantity of each
ingredients of the drink.
Service Mode
1
2
3
5
4
6 7 8 9 10
A
B
C
To Next Page
