SERVICE & INSTALLATION MANUAL - Symbol
6.7 Media Tab
The brewer plays video on the screen while a beverage is prepared and as a screen saver when
the machine is not in use.
To access the screen below, tap in order on the top left, bottom left and bottom right corners of
the screen (see section6) and select the Media tab.
6.7.1 Current Playlist Sub Tab
The Current Playlist sub tab allows to edit the main playlist for videos playing during
beverage preparation.
1. This checkbox is used to enable the playlist.
2. This field is used to change the name of the playlist.
3. This section lists the videos selected for the current playlist.
4. This button is used to add a video from the video storage on the brewer.
5. The source indicates where the playlist comes from. Personalized videos can be added
with Sophia (Optimum license required).
6. This button is used to remove a video from the current playlist.
7. This button is used to see a preview of the video.
8. This button is used to discart or save all changes. Any unsaved changes will be lost.
6.7.2 Next Playlist Sub Tab
This sub tab is used to prepare
the next playlist and schedule it to
become the current playlist at a
specific time.
Parameters are the same as in the
Current Playlist sub tab.
A start date and time must be set
using the calendar accessible through
the Date and Time button.
Service Mode
8
4
6
1
2
3
7
5
