SERVICE & INSTALLATION MANUAL - Symbol
Initial Setup
4.8 Loading Products
Product availability may vary depending on the model.
Do not overfill the hoppers and canisters.
4.8.1 Soluble Ingredients Canisters
1. Unlock and open the door.
2. Lift the chute up to avoid product to fall
out of the canisters during loading.
3. Pull the canister outward and remove
its lid, then fill it with the appropriate
ingredient.
4. Close the lid and reinstall the canister in
the machine, making sure it touches the
back panel.
5. Push the chute down and replace it on its
support.
6. Close the machine door and lock it.
Chute
Support
Lid
Chute
Canister
Bean Hoppers Locks
Soluble Canisters (4.8.1)
Door Lock
Bean Hoppers (4.8.2)
Ground Coffee
Canister (4.8.3)
