SERVICE & INSTALLATION MANUAL - Symbol
Initial Setup
4.1.5 Clearance
Unit Clearances Allowance for
Height 30.50" 36.50" Opening top lid.
Width 17.75" 27.75" Accessing lock (right side) and opening door (left side).
Depth 23.94" 18.78" Minimum countertop depth
Back
Clearance
1.75" Clearance for water hookup, hoses and adequate air
circulation.
See Annex1 for chute hole positioning.
Cut the chute hole in the counter top prior to installing the machine on it.
See Annex2 for a diagram illustrating required clearance.
4.2 Brewer Specifications
4.2.1 Hopper & Canister Capacities
Whole Bean Hoppers
1-Bean Model ............................. 5.0 lb (2.3kg)
2-Bean Model ............................. 2.5 lb (1.2kg) and 3.0 lb (1.4kg)
Left Hopper Extensions ..... 0.8 lb (0.3 kg)
Right Hopper Extensions ... 0.9 lb (0.4 kg)
Soluble Canisters
*
................................ 3.0 lb (1.4kg)
Ground Coffee Canister
*
....................... 0.9 lb (0.4kg)
*Quantity of canisters may vary depending on the model
4.2.2 Water Tank
Capacity ................................................ 0.74 gallons (2.8L)
Water valves .......................................... 5 simple valves
Heating element ..................................... 1250 watts
4.2.3 Electrical Specifications (Brewer Consumption)
120V AC / 60 Hz - 12A
4.2.4 Weight
Up to 105 lb (47.63 kg)
