EVOCA Opera Touch - Periodical Operations

02-2023 6095 00 3
POSITIONING THE VENDING
MACHINE
The machine is not suitable for installation
outdoors. It must be installed in a dry room
and far from any source of heat at a tem-
perature ranging from 41 °F to 93 °F. It can
not be installed in a room where water jets
are used for cleaning (e.g. large kitchens,
etc.).
The machine must be installed near a wall,
but in such a way that the back is min. 1,57
inch far from the wall in order to provide for
regular ventilation; in no case, it shall be
covered with any piece of cloth or alike.
The maximum inclination shall not exceed
2 degrees. If necessary, level it by using the
adjustable feet.
TECHNICAL FEATURES
23.62
47,24
29,13
49,21
72,04
Fig. 2
Weight 297 lb
Voltage 120 VAC
Frequency 60 Hz
Maximum power 1850 W
NoisE lEvEl
The continuous sound pressure level is
below 70 dB.
